Written down, then run

Short technical posts about mechanisms that are usually drawn and rarely executed. Each one simulates the thing first, asserts the claim it is about to make, and animates the simulation — so a post whose claim stops being true fails to render rather than going out wrong.

Graph theory, computed

Every state on screen came from running the algorithm on the graph you passed in

  1. The picture cannot show a state the algorithm did not reach

    Twenty graph algorithms — Dijkstra to max flow, Kruskal to König, Prüfer to Gale–Shapley — computed once and drawn as SVG storyboard, five of them as Manim video too. A graph that makes the claim false is refused with the witness: the cycle, the negative cycle, the odd-degree vertices.

    Graph algorithms

  2. Fourteen more algorithms, each with the witness it refuses on

    A graph-theory course left a marker wherever the figure it wanted did not exist; fourteen were algorithms. Prüfer codes, Gale–Shapley, Havel–Hakimi, Floyd–Warshall, Hamiltonian search, Turán and Mycielski — computed from the graph you pass in, refused with the witness when the claim is false.

    Graph algorithms

  3. Matching and cover: why König's theorem is a certificate

    A maximum matching and a minimum vertex cover of the same size prove each other optimal. Computed from the matching, checked edge by edge, and drawn only then.

    Planned

Dataflow, executed

How data moves through an accelerator and across a cluster

  1. The pipeline bubble 1F1B doesn't fix

    GPipe and 1F1B finish on the same cycle and idle for the same number of stage-slots. What 1F1B buys is activation memory — 23 sets against 6 — which is the number that decides whether a model fits.

    Pipeline parallelism

  2. Why the systolic array feeds itself diagonally

    The skew is not a convention. Entries entering on cycle t are exactly the anti-diagonal, because that is the only arrival time at which a multiply meets the running sum it belongs to — and each weight is then read from SRAM once instead of once per output.

    Systolic dataflow

  3. Ring all-reduce: the bytes per rank don't grow

    Reduce-scatter then all-gather, executed chunk by chunk. Each rank sends under 2D regardless of ring size; what grows with the ring is the number of serial hops, which is a latency story rather than a bandwidth one.

    Collectives

  4. Interleaved pipelines: the bubble that does move

    Splitting each device's layers into several non-contiguous chunks genuinely shrinks the bubble, and pays for it in cross-device traffic. Same treatment: simulated, measured, animated.

    Planned

Linear algebra, four ways

The operations underneath the dataflow above

  1. Matrix multiplication, four ways

    AB is taught as a rule for filling in entries. Three other readings of the same product explain what it is for — and two of them are what a systolic array and tensor parallelism already execute.

    Matrix multiplication

  2. Low rank, and what it throws away

    If AB is a sum of rank-1 terms, keeping only the largest few is an approximation with a measurable error. Same treatment: computed, bounded, animated from the computation.

    Planned

Constructive geometry

Compass, straightedge, and figures that prove what they assert

  1. The picture is not the proof

    1.618 is not the golden ratio, and every tool that answers by measuring its own drawing says it is. Ruler and compass reach exactly the tower of quadratic extensions of Q — computing in that field turns a claim about a figure into a decision rather than an estimate.

    Exact arithmetic

  2. Why the cube cannot be doubled

    Every constructible number has degree a power of two, and a cube root does not. The impossibility proof falls out of the same arithmetic the constructions are drawn with.

    Planned
